This floodlight mast is manufactured from high quality round steel tubing and is hot-dip galvanised inside and outside.
The floodlight masts are equipped with a flush-mounted mast door with an internal device bridge for the mast fuse box and an internal earthing connection. From a height of 14 metres, conical lightning poles are supplied in two parts and are easy to connect using a push-fit joint. Each tubular steel mast is individually designed for your installation site. This floodlight pole is weather-resistant thanks to its hot-dip galvanisation and can be coated in RAL or DB colors on request.
As the manufacturer, Fonatsch GmbH is in possession of all necessary quality certificates.
Light point height:
18,0
Design:
- Made from high quality conical round tubes
- This mast is supplied in two parts and is easy to connect using a push-fit joint
- 1 or 2 flush-mounted mast doors 600 x 155 mm with internal device bridge for cable junction box and ballast
- Door lock with stainless steel screw M8/A2
- Internal earth connection with M8/A2 stainless steel screw
- Double cable entry, 180° offset, 150 x 50 mm
- Inside and outside hot-dip galvanised in accordance with ÖNORM EN ISO 1461
- Construction in accordance with EN 40-2, CE certified in accordance with DIN EN 1090
- Additional coating in RAL and DB colors of your choice possible
- Version with flange plate and anchor basket possible on request
Riser system:
These masts can optionally be equipped with climbing rungs and fall protection rope as a climbing system
Application:
For lightning sport facilities and large areas
Static design:
Static design depending on floodlight type, number of floodlights, floodlight inclination and installation location
